Technical Details

The Food Fort was built by Concession Nation in Florida and delivered on June 14th, 2023.

Equipment Schedule

This file has a lot of details including model numbers for most of the equipment installed in the trailer:

Concession Nation Estimate.pdf

Ice Maker (Blueair BLUI-250A)

• Service Manual
• Spec Sheet
• User Manual

Range / Oven (Imperial IR-6-C)

• User Manual
• Spec Sheet

Freezer (TurboAir MUF-60-N Undercounter)

• Manual
• Uses R-290 Refrigerant

Trailer Specifications

• Gross Vehicle Weight Rating (GVWR): 14,000 lbs
• Tongue Weight: 1,700 lbs
• Total Trailer Weight (including Tongue Weight): 10,080 lbs
• Height: over 12’
• 7' Interior Height
• We need a heavy duty pickup truck, like a Ford 350, to tow this

Over-the-road Generator

We use an external generator so that we can fill up the refrigerator and freezer in Reno and tow everything into Burning Man. There used to be one mounted on the tongue but this was not a good design. Currently we ratchet a portable generator down in the bed of the rental pickup truck that we use to tow the trailer. This needs to be a pretty heavy duty generator (like a 9000 watts or more) with 30 amp 207/240 output to power the condenser for the refrigerator.
